The StressTel T-Mike Velocity
is a compact, easy-to-use and rugged gauge for measurement of material velocity in
materials such as cast iron. The operator simply inputs the material thickness,
couples the transducer to the part and the material velocity is displayed. The T-Mike V
can also be used as a conventional thickness gauge.
T-Mike V key features include auto calibration, amber colored display with backlight
and fast-and-easy battery replacement.
Ergonomically designed to fit comfortably in your hand, the T-Mike V is built to last,
with an environmentally sealed weather resistant case and keypad. |
|
|
|
Unit Features |
|
|
|
| 1. |
Lemo quick-disconnect connectors. |
| 2. |
Battery charger connector/data port. |
| 3. |
Built-in auto-probe zero block. |
| 4. |
Coupling indicator. |
| 5. |
Backlit LCD indicates modes, measurements and
icons. |
| 6. |
Lightweight aluminum case. |
| 7. |
Weather resistant sealed keypad. |
| 8. |
Power key. |
| 9. |
One step material calibration key. |
| 10.
|
Arrow keys for material selction. |
| 11. |
Operator selectable Metric (MM) or English (IN)
units. |
|
|
|
|
Display |
|
|
|
| Measurements: |
4 1/2 digit backlight LCD readout. |
| Coupling Check: |
NO ECHO display. |
| Battery Check: |
LOW BAT display flashes to indicate battery
replacement. |
| Units: |
English/Metric selectable
IN or MM displayed |
|
|
|
|
Description |
|
|
|
| Unit
Size: |
2.5 inches wide (64 mm)
4.5 inches long (114 mm)
1.25 inches deep (33 mm)
11 ounces (312 grams) |
| Case: |
Sealed aluminum case. |
| Keypad: |
Water
resistant keypad. |
|
|
|
|
Material |
|
|
|
Fast and easy calibration for wide variety of
metals and plastics including steels, stainless steels, aluminum, cast iron and
plexiglass. |
|
|
|
Power Supply |
|
|
|
Four AA alkaline or NiCad batteries.
Interchangeable and easy to access.
Approximately 300 hours of continuous operation - 80 hours with backlight. |
|
|
|
Operation |
|
|
|
| Material velocity range: |
0.01 to 0.59 inches per micro-second. |
| Measuring range velocity: |
To 0.999 inches per micro-second. |
| Display resolution: |
0.001 in. ( 0.01mm). |
| Allowable surface temperature: |
0°
F to 250° F (-18° C to 120° C)
High temperature probes available to 650° F (340°C) |
|
|
|
T-Mike V Kit Contents: |
|
|
|
* |
T-Mike
V Ultrasonic Thickness Gauge |
* |
1/2"
x 2.25 MHz Transducer ID 20002; P/N 063-200-006 (recommended) |
* |
Operation Manual |
* |
Four "AA" Batteries (Alkaline or NiCad) |
* |
Battery Charger (if NiCad battery operated) |
* |
Couplant |
* |
Plastic Instrument Accessory Case |
* |
Certificate of Calibration |
|
|
|
|
Warranty |
|
|
|
All T-Mike Corrosion Thickness Gauges have a full
two-year warranty on parts and labor excluding batteries, transducer and cable.
Specifications subject to change without notice. |
|
