Imason Special probes are dedicated to particular applications that require different solutions than those of conventional immersion, contact or phased array probes.

They make it possible to solve new inspections while keeping a high level of acoustical performances

The main specialties of these probes are :

• Particular geometry to match the inspection setup
• Use of advanced piezocomposite material to reach particular electroacoustical performances ( power, bandwidth, sensitivity..)
• Integration of electrical impedance matching  or electronic components (multiplexors, preamplifiers, ...)
• Adaptation to harsh environmental conditions (temperature, pressure, nuclear radiation...)

Ultrasonic heads for tube inspection by the inside Focused and angled active areas for TOFD technique 8.5 mm diameter

Single element transducers Dry contact technique Spot focused beam at the contact point

Bi element transducers with acoustic insulation Aspherically focused active area Soft material wedge to match cylindrical interface Large aperture Integrated water irrigation system

4 transducers ultrasonic head Focused active areas Integrated probe holder Soft material wedges Integrated water irrigation system

Angled beam transducers 2mm thick probes Integrated water irrigation system

Single element transducer 180°C immersion use Aspherically focused active area Large aperture Additional electrical matching housing

Annuar phased array transducer Aspherical surface to focus through a cylindrical interface Center element with higher frequency
